Altair Accelerator

The AcceleratorLogParser.py script queries the Accelerator results database, parses the job completion data, and saves it into a CSV file.

Video walkthrough

The fastest way to learn about using HPC Cost Simulator with Altair's Accelerator (NC) is to watch this short walkthrough.

Collecting the data

To see data collection command syntax, run:

source setup.sh
./AcceleratorLogParser.py --show-data-collection-cmd

For example, as of this writing, the command is:

nc cmd vovsql_query -e "select jobs.id, jobs.submittime, jobs.starttime, jobs.endtime, resources.name, jobs.exitstatus, jobs.maxram, jobs.maxvm, jobs.cputime, jobs.susptime from jobs inner join resources on jobs.resourcesid=resources.id" > sql-output.txt

This command should run on a node connected to the Altair Accelerator head node, and with a user with permissions to see the jobs from all users.

Note: To be able to run the command, you first need to source the vovrc.sh script located in your /common/etc subfolder of your Altair install folder.

Parsing the Job Completion Data

The parsed data will be written in the output directory which will be created if it does not exist.

./AcceleratorLogParser.py \
    --sql-output-file sql-output.txt \
    --output-csv output/jobs.csv

Full Syntax

usage: AcceleratorLogParser.py [-h]
                               (--show-data-collection-cmd | --sql-output-file SQL_OUTPUT_FILE | --sql-input-file SQL_INPUT_FILE)
                               [--output-csv OUTPUT_CSV]
                               [--default-mem-gb DEFAULT_MEM_GB]
                               [--starttime STARTTIME] [--endtime ENDTIME]
                               [--debug]

Parse Altair Accelerator logs.

optional arguments:
  -h, --help            show this help message and exit
  --show-data-collection-cmd
                        Show the command to create the SQL_OUTPUT_FILE.
                        (default: False)
  --sql-output-file SQL_OUTPUT_FILE
                        File where the output of sql query will be written.
                        Cannot be used with --sql-input-file. Required if
                        --sql-input-file not set. (default: None)
  --sql-input-file SQL_INPUT_FILE
                        File with the output of sql query so can process it
                        offline. Cannot be used with --sql-output-file.
                        Required if --sql-output-file not set. (default: None)
  --output-csv OUTPUT_CSV
                        CSV file with parsed job completion records (default:
                        None)
  --default-mem-gb DEFAULT_MEM_GB
                        Default amount of memory (in GB) requested for jobs
                        that do not have a memory request. (default: 0.0)
  --starttime STARTTIME
                        Select jobs after the specified time. Format YYYY-MM-
                        DDTHH:MM:SS (default: None)
  --endtime ENDTIME     Select jobs before the specified time. Format YYYY-MM-
                        DDTHH:MM:SS (default: None)
  --debug, -d           Enable debug mode (default: False)

What's next?

Once completed, you can run step #3 (cost simulation) by following the instructions in for the JobAnalyzer Since you already generated a CSV file, you will use JobAnalyzer with the csv option.
