Bedrock Agent Gateway - S3 CRUD Operations

The genesis of this project was wanting to perform CRUD operations against a S3 bucket from within Quick Suites Flow. Now using this remote MCP server, you can add this to Quick Suites integration, and then call upon the actions from within a Flow.

This is a secure gateway to Amazon Bedrock AgentCore that provides CRUD operations on S3 buckets through a Lambda function. The system uses JWT authentication with Amazon Cognito and exposes MCP (Model Context Protocol) actions for client interactions.

Description

This project creates a complete infrastructure for secure S3 operations through Amazon Bedrock AgentCore Gateway. It enables applications to perform Create, Read, Update, and Delete operations on S3 objects through a standardized MCP interface with OAuth 2.0 authentication.

Key Features

• 🔐 Secure Authentication: OAuth 2.0 client credentials flow with Amazon Cognito
• 📁 Full S3 CRUD Operations: Create, read, update, delete, and list S3 objects
• 🖼️ Binary File Support: Handles text files, PDFs, images, and all binary formats
• 🛡️ Security First: Least privilege IAM policies and encrypted S3 storage
• 🚀 Serverless Architecture: Lambda-based with automatic scaling
• 📊 Comprehensive Logging: CloudWatch integration for monitoring and debugging
• 🔧 MCP Protocol: Standardized Model Context Protocol for AI agent interactions

Architecture Components

• Amazon Bedrock AgentCore Gateway: MCP protocol endpoint
• AWS Lambda Function: S3 operations handler with binary file support
• Amazon S3 Bucket: Encrypted storage with unique naming
• Amazon Cognito: OAuth 2.0 authentication provider
• IAM Roles: Least privilege security policies
• CloudWatch Logs: Monitoring and debugging

Installation

Prerequisites

• AWS CLI configured with appropriate permissions
• AWS account with access to:
• Amazon Bedrock AgentCore
• AWS Lambda
• Amazon S3
• Amazon Cognito
• AWS IAM
• Amazon CloudWatch

Deployment Steps

1. Clone the repository

   git clone <repository-url>
   cd bedrock-agent-gateway


2. Deploy the CloudFormation stack

   aws cloudformation create-stack \
     --stack-name bedrock-agent-gateway \
     --template-body file://template.yaml \
     --capabilities CAPABILITY_NAMED_IAM \
     --region us-west-2


3. Monitor deployment progress

   aws cloudformation wait stack-create-complete \
     --stack-name bedrock-agent-gateway \
     --region us-west-2


4. Retrieve deployment outputs

   aws cloudformation describe-stacks \
     --stack-name bedrock-agent-gateway \
     --region us-west-2 \
     --query "Stacks[0].Outputs"


Configuration Parameters

The CloudFormation template accepts the following parameters:

Parameter	Description	Default	Required
S3BucketName	Base name for S3 bucket (made unique with account ID)	bedrock-gateway-bucket	No
Environment	Environment name (dev/staging/prod)	dev	No
ProjectName	Project name for resource naming	bedrock-agent-gateway	No
EnableLogging	Enable CloudWatch logging	true	No
TokenExpirationHours	OAuth token expiration (1-24 hours)	1	No

Usage

Authentication

The system uses OAuth 2.0 client credentials flow. After deployment, you'll receive:

• Gateway Endpoint URL: The MCP protocol endpoint
• Client ID: Cognito User Pool Client ID
• Client Secret: Cognito User Pool Client Secret
• Token Endpoint: OAuth 2.0 token endpoint

Getting an Access Token

curl -X POST https://your-cognito-domain.auth.region.amazoncognito.com/oauth2/token \
  -H "Content-Type: application/x-www-form-urlencoded" \
  -d "grant_type=client_credentials&client_id=YOUR_CLIENT_ID&client_secret=YOUR_CLIENT_SECRET&scope=bedrock-agent-gateway-dev-api/s3:crud"

MCP Operations

1. Upload a Text File

{
  "key": "documents/readme.txt",
  "content": "Hello, World! This is a text file.",
  "metadata": {
    "author": "user",
    "version": "1.0"
  }
}

2. Upload a Binary File (PDF/Image)

{
  "key": "files/document.pdf",
  "content": "JVBERi0xLjQKJcOkw7zDtsO8w7HDqMO6...",
  "is_base64": true,
  "metadata": {
    "type": "document",
    "size": "large"
  }
}

3. Read a File

{
  "key": "documents/readme.txt"
}

Response for text files:

{
  "success": true,
  "content": "Hello, World! This is a text file.",
  "is_base64": false,
  "content_type": "text/plain",
  "content_length": 34
}

Response for binary files:

{
  "success": true,
  "content": "JVBERi0xLjQKJcOkw7zDtsO8w7HDqMO6...",
  "is_base64": true,
  "content_type": "application/pdf",
  "content_length": 12345
}

4. List Files

{
  "prefix": "documents/",
  "max_keys": 10
}

5. Delete a File

{
  "key": "documents/readme.txt",
  "confirm": true
}

Supported File Types

• Text Files
• Binary Files (See Quick Suite documentation for supported types)

Testing

Unit Tests

Run the Python tests for OAuth functionality:

python -m pytest tests/ -v

Integration Testing

Test the deployed Lambda function:

aws lambda invoke \
  --function-name bedrock-dev-s3-ACCOUNT-REGION \
  --payload '{"key": "test.txt", "content": "Hello World"}' \
  --region us-west-2 \
  response.json

Monitoring and Logging

CloudWatch Log Groups

The system creates three log groups:

• /aws/lambda/bedrock-ENVIRONMENT-s3-ACCOUNT-REGION - Lambda function logs
• /aws/bedrock/PROJECT-ENVIRONMENT-gateway - Gateway request/response logs
• /aws/security/PROJECT-ENVIRONMENT-events - Security and authentication logs

Monitoring Commands

# View Lambda function logs
aws logs tail /aws/lambda/bedrock-dev-s3-ACCOUNT-REGION --follow

# Check gateway metrics
aws cloudwatch get-metric-statistics \
  --namespace AWS/BedrockAgentCore \
  --metric-name Invocations \
  --start-time 2024-01-01T00:00:00Z \
  --end-time 2024-01-02T00:00:00Z \
  --period 3600 \
  --statistics Sum

Security

IAM Policies

The system implements least privilege access:

• Lambda Execution Role: Only access to the specific S3 bucket created by the stack
• Bedrock Gateway Role: Only permission to invoke the Lambda function
• S3 Bucket: Encrypted at rest, public access blocked, versioning disabled

Authentication Flow

1. Client requests OAuth token using client credentials
2. Cognito validates credentials and returns JWT access token
3. Client includes JWT token in MCP requests to gateway
4. Gateway validates JWT token against Cognito
5. Authorized requests are forwarded to Lambda function

Best Practices

• Rotate client secrets regularly
• Use short-lived access tokens (1-24 hours)
• Monitor CloudWatch logs for suspicious activity
• Implement request rate limiting in client applications

Cleanup

To remove all resources:

# Empty the S3 bucket first (if it contains objects)
aws s3 rm s3://your-bucket-name --recursive

# Delete the CloudFormation stack
aws cloudformation delete-stack \
  --stack-name bedrock-agent-gateway \
  --region us-west-2

# Wait for deletion to complete
aws cloudformation wait stack-delete-complete \
  --stack-name bedrock-agent-gateway \
  --region us-west-2

Troubleshooting

Common Issues

1. Lambda function name too long

2. Solution: The template automatically generates short, unique names

3. S3 bucket already exists

4. Solution: The template creates buckets with unique names using account ID and region

5. Cognito domain already exists

6. Solution: Delete existing Cognito domains or use a different project name

7. Binary file upload fails

8. Solution: Ensure is_base64: true is set for binary content

Debug Commands

# Check stack events for errors
aws cloudformation describe-stack-events \
  --stack-name bedrock-agent-gateway \
  --region us-west-2

# Test Lambda function directly
aws lambda invoke \
  --function-name bedrock-dev-s3-ACCOUNT-REGION \
  --payload '{"key": "test.txt"}' \
  --region us-west-2 \
  response.json && cat response.json

Contributing

1. Fork the repository
2. Create a feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes (git commit -m 'Add amazing feature')
4. Push to the branch (git push origin feature/amazing-feature)
5. Open a Pull Request

Development Setup

# Install development dependencies
pip install -r requirements.txt

# Run tests
python -m pytest tests/ -v

# Validate CloudFormation template
aws cloudformation validate-template --template-body file://template.yaml

License

This project is licensed under the MIT License - see the LICENSE file for details.

Authors and Acknowledgment

• Primary Developer: David Girling
• AWS Services: Amazon Bedrock AgentCore, AWS Lambda, Amazon S3, Amazon Cognito
• Protocol: Model Context Protocol (MCP) specification
