AgentCore Integration

Amazon Bedrock AgentCore enables you to deploy and operate highly capable AI agents securely, at scale. It offers infrastructure purpose-built for dynamic agent workloads, powerful tools to enhance agents, and essential controls for real-world deployment. AgentCore services can be used together or independently and work with any framework including CrewAI, LangGraph, LlamaIndex, and Strands Agents, as well as any foundation model in or outside of Amazon Bedrock, giving you ultimate flexibility. AgentCore eliminates the undifferentiated heavy lifting of building specialized agent infrastructure, so you can accelerate agents to production.

Prerequisites

1. Deploy Amazon Bedrock AgentCore Agent Runtime in your AWS account

The CDK deployment automatically configures the required IAM permissions (bedrock-agentcore:InvokeAgentRuntime and bedrock-agentcore:ListAgentRuntimes).

Using AgentCore

1. Agent Discovery

Agents are automatically discovered using the listAgents GraphQL query, which calls list_agent_runtimes() on the bedrock-agentcore-control client. Only users with admin or workspace_manager roles can access this query.

2. Agent Selection

In the chat interface:

• Agents appear in a separate dropdown labeled "Select an agent (optional)"
• Agents display using agentRuntimeName as the label
• The agentRuntimeArn is used as the value
• Agent selection is optional - you can use regular models instead

3. Conversation

• When an agent is selected, the system uses modelInterface: "agent"
• Thinking Steps: The agent's reasoning process is displayed in a collapsible section with:
  • Compact vertical timeline layout with connecting lines
  • Real-time updates during streaming responses
  • Visual indicators (emojis) for different agent actions
  • Click to expand/collapse the full thinking process
• Streaming: Both thinking steps and response content stream in real-time
• Tool Usage: When agents use tools, thinking steps show tool invocation and execution

Interface Between Agent and Chatbot

Request Format

The chatbot sends the complete request record as JSON payload to the agent's @app.entrypoint function:

{
    "userId": "user-id",
    "userGroups": ["group1", "group2"],
    "data": {
        "text": "User message",
        "agentRuntimeArn": "arn:aws:bedrock-agentcore:region:account:runtime/agent-id",
        "sessionId": "session-uuid",
        "conversation_history": [
            {"role": "user", "content": "Previous user message"},
            {"role": "assistant", "content": "Previous assistant response"}
        ],
        # Additional fields from original request...
        "modelName": "anthropic.claude-3-5-sonnet-20241022-v2:0",
        "modelKwargs": {
            "temperature": 0.7,
            "topP": 0.9,
            "maxTokens": 4000,
            "streaming": true
        }
    }
}

Key Fields:

• userId: User identifier from the chatbot session
• userGroups: User's group memberships for authorization
• data.text: The user's current message
• data.agentRuntimeArn: The selected agent's ARN
• data.sessionId: Session identifier for conversation continuity
• data.conversation_history: Array of previous messages with role and content fields (up to 20 recent messages)
• data.modelName: Bedrock model identifier (if provided)
• data.modelKwargs: Model configuration including streaming preference

Important Notes:

• The conversation_history is automatically added by the handler from DynamoDB
• Messages are converted to simple {role, content} objects
• The entire original request record is passed through, so agents receive all original fields

Response Format

The agent returns Server-Sent Events (SSE) streaming data that the chatbot processes:

Streaming SSE Format:

# Thinking steps (agent reasoning)
data: {"type": "thinking", "content": "💭 Assistant starting..."}
data: {"type": "thinking", "content": "🔧 Calling calculator..."}
data: {"type": "thinking", "content": "🧠 Analyzing the calculation..."}
data: {"type": "thinking", "content": "✅ Block complete"}

# Response content (actual answer)
data: {"type": "content", "content": "The result is "}
data: {"type": "content", "content": "42"}

Non-streaming Response:

{
    "result": "Agent's complete response text"
}

Event Processing:

• Thinking Events: type: "thinking" events are displayed in the expandable thinking steps section
• Content Events: type: "content" events are accumulated to build the final response
• Visual Indicators: Thinking steps support emoji indicators for different agent actions (needs to be sent by the agent):
  • 💭 Message start/thinking
  • 🔧 Tool usage
  • 🧠 Reasoning content
  • 📚 Citations
  • ✅ Completion markers
  • ⏸️ Tool execution
  • 🏁 Response complete

The above are CoverseStream events sent by a Amazon Bedrock more info here

Security

• Session Isolation: Each conversation maintains separate session state (Handled by AgentCore)
• Error Handling: Graceful fallback with error recovery for session history

Getting Started

QuickStart: Your First Agent in 5 Minutes! 🚀

Simple Agent Example

Here's a minimal agent implementation that demonstrates the core concepts:

import boto3
import json
from bedrock_agentcore import BedrockAgentCoreApp
from strands import Agent
from strands.models import BedrockModel
from strands_tools import calculator, current_time

app = BedrockAgentCoreApp()
session = boto3.Session(region_name='il-central-1')
bedrock_model = BedrockModel(boto_session=session)

agent = Agent(
    system_prompt="You are a helpful AI assistant that can use tools to answer questions.",
    model=bedrock_model,
    tools=[calculator, current_time],
)

@app.entrypoint
async def invoke(payload, context):
    """Main agent function with streaming support"""
    # Extract request data
    user_message = payload["data"]["text"]
    conversation_history = payload["data"].get("conversation_history", [])
    is_streaming = payload["data"].get("modelKwargs", {}).get("streaming", False)

    # Configure model from payload (if provided)
    if "modelName" in payload["data"]:
        bedrock_model.update_config(
            model_id=payload["data"]["modelName"],
            temperature=payload["data"]["modelKwargs"].get("temperature", 0.7),
            streaming=is_streaming,
        )

    if is_streaming:
        async def generate_sse():
            async for event in agent.stream_async(user_message):
                if "event" in event:
                    bedrock_event = event["event"]

                    # Handle different event types
                    if "contentBlockDelta" in bedrock_event:
                        delta = bedrock_event["contentBlockDelta"]["delta"]

                        if "text" in delta:
                            # Stream response content
                            sse_data = json.dumps({"type": "content", "content": delta["text"]})
                            yield f"data: {sse_data}\n\n"

                        elif "reasoningContent" in delta:
                            # Stream thinking steps
                            reasoning = delta["reasoningContent"]["text"]
                            sse_data = json.dumps({"type": "thinking", "content": f"🧠 {reasoning}"})
                            yield f"data: {sse_data}\n\n"

                    elif "contentBlockStart" in bedrock_event:
                        start_data = bedrock_event["contentBlockStart"]["start"]
                        if "toolUse" in start_data:
                            tool_name = start_data["toolUse"]["name"]
                            sse_data = json.dumps({"type": "thinking", "content": f"🔧 Using {tool_name}"})
                            yield f"data: {sse_data}\n\n"

        return generate_sse()
    else:
        # Non-streaming response
        result = agent(user_message)
        return {"result": result.message}

if __name__ == "__main__":
    app.run()

Key Components:

• BedrockAgentCoreApp(): Main application wrapper
• Agent(): Core agent with system prompt, model, and tools
• @app.entrypoint: Decorator for the main handler function
• Streaming: Uses agent.stream_async() for real-time responses
• Event Processing: Handles Bedrock events to extract thinking and content
• SSE Format: Returns properly formatted Server-Sent Events

Troubleshooting

Agent Not Available

• Verify agent is deployed and active in Bedrock
• Confirm agent ARN matches the exact pattern required
• Check that your user has admin or workspace_manager role

Streaming Issues

• Check WebSocket connection in browser developer tools
• Verify session management in CloudWatch logs
• Ensure agent provides data in expected thinking/event format

Performance

• Agents may take longer than standard models due to reasoning complexity
• Monitor CloudWatch metrics for agent invocation times
• Conversation history is limited to prevent payload size issues
